Data Extraction Agent

Active Agent provides data extraction capabilities to parse structured data from unstructured text, images, or PDFs.

Setup

Generate a data extraction agent:

rails generate active_agent:agent data_extraction parse_content

Agent Implementation

data_extraction_agent.rb

class DataExtractionAgent < ApplicationAgent
  before_action :set_multimodal_content, only: [ :parse_content ]

  def parse_content
    prompt(
      message: params[:message] || "Parse the content of the file or image",
      image_data: @image_data,
      file_data: @file_data,
      output_schema: params[:output_schema]
      )
  end

  def describe_cat_image
    prompt(
      message: "Describe the cat in the image",
      image_data: CatImageService.fetch_base64_image
      )
  end

  private
  def set_multimodal_content
    if params[:file_path].present?
      @file_data ||= "data:application/pdf;base64,#{Base64.encode64(File.read(params[:file_path]))}"
    elsif params[:image_path].present?
    end
  end
end

chart_schema.json.erb

{
  "format": {
    "type": "json_schema",
    "name": "chart_schema",
    "schema": {
      "type": "object",
      "properties": {
        "title": {
          "type": "string",
          "description": "The title of the chart."
        },
        "data_points": {
          "type": "array",
          "items": {
            "$ref": "#/$defs/data_point"
          }
        }
      },
      "required": ["title", "data_points"],
      "additionalProperties": false,
      "$defs": {
        "data_point": {
          "type": "object",
          "properties": {
            "label": {
              "type": "string",
              "description": "The label for the data point."
            },
            "value": {
              "type": "number",
              "description": "The value of the data point."
            }
          },
          "required": ["label", "value"],
          "additionalProperties": false
        }
      }
    }
  }
}

resume_schema.json.erb

{
  "format": {
    "type": "json_schema",
    "name": "resume_schema",
    "schema": {
      "type": "object",
      "properties": {
        "name": {
          "type": "string",
          "description": "The full name of the individual."
        },
        "email": {
          "type": "string",
          "format": "email",
          "description": "The email address of the individual."
        },
        "phone": {
          "type": "string",
          "description": "The phone number of the individual."
        },
        "education": {
          "type": "array",
          "items": {
            "$ref": "#/$defs/education"
          }
        },
        "experience": {
          "type": "array",
          "items": {
            "$ref": "#/$defs/experience"
          }
        }
      },
      "required": ["name", "email", "phone", "education", "experience"],
      "additionalProperties": false,
      "$defs": {
        "education": {
          "type": "object",
          "properties": {
            "degree": {
              "type": "string",
              "description": "The degree obtained."
            },
            "institution": {
              "type": "string",
              "description": "The institution where the degree was obtained."
            },
            "year": {
              "type": "integer",
              "description": "The year of graduation."
            }
          },
          "required": ["degree", "institution", "year"],
          "additionalProperties": false
        },
        "experience": {
          "type": "object",
          "properties": {
            "job_title": {
              "type": "string",
              "description": "The job title held."
            },
            "company": {
              "type": "string",
              "description": "The company where the individual worked."
            },
            "duration": {
              "type": "string",
              "description": "The duration of employment."
            }
          },
          "required": ["job_title", "company", "duration"],
          "additionalProperties": false
        }
      }
    },
    "strict": true
  }
}

Basic Image Example

Image Description

Active Agent can extract descriptions from images without structured output:

prompt = DataExtractionAgent.describe_cat_image

Basic Cat Image Response Example

activeagent/test/agents/data_extraction_agent_test.rb:21

# Response object
#<ActiveAgent::GenerationProvider::Response:0x3264
  @message=#<ActiveAgent::ActionPrompt::Message:0x3278
    @action_id=nil,
    @action_name=nil,
    @action_requested=false,
    @charset="UTF-8",
    @content="The cat in the image appears to have a primarily dark gray coat with a white patch on its chest. It has a curious expression and is positioned in a relaxed manner. The background suggests a cozy indoor environment, possibly with soft bedding and other hous...",
    @role=:assistant>
  @prompt=#<ActiveAgent::ActionPrompt::Prompt:0x328c ...>
  @content_type="text/plain"
  @raw_response={...}>

# Message content
response.message.content # => "The cat in the image appears to have a primarily dark gray coat with a white patch on its chest. It has a curious expression and is positioned in a relaxed manner. The background suggests a cozy indoor environment, possibly with soft bedding and other household items visible."

Image: Parse Chart Data

Active Agent can extract data from chart images:

prompt = DataExtractionAgent.with(
  image_path: sales_chart_path
).parse_content

Basic Chart Image Response Example

activeagent/test/agents/data_extraction_agent_test.rb:112

# Response object
#<ActiveAgent::GenerationProvider::Response:0x32b4
  @message=#<ActiveAgent::ActionPrompt::Message:0x32c8
    @action_id=nil,
    @action_name=nil,
    @action_requested=false,
    @charset="UTF-8",
    @content="The image is a bar chart titled \"Quarterly Sales Report\" that displays sales revenue for the year 2024 by quarter. \n\n- **Y-axis** represents sales revenue in thousands of dollars, ranging from $0 to $100,000.\n- **X-axis** lists the four quarters: Q1, Q2, Q...",
    @role=:assistant>
  @prompt=#<ActiveAgent::ActionPrompt::Prompt:0x32dc ...>
  @content_type="text/plain"
  @raw_response={...}>

# Message content
response.message.content # => "The image is a bar chart titled \"Quarterly Sales Report\" that displays sales revenue for the year 2024 by quarter. \n\n- **Y-axis** represents sales revenue in thousands of dollars, ranging from $0 to $100,000.\n- **X-axis** lists the four quarters: Q1, Q2, Q3, and Q4.\n\nThe bars are colored as follows:\n- Q1: Blue\n- Q2: Green\n- Q3: Yellow\n- Q4: Red\n\nThe heights of the bars indicate the sales revenue for each quarter, with Q4 showing the highest revenue."

Structured Output

Active Agent supports structured output using JSON schemas. Define schemas in your agent's views directory (e.g., app/views/data_extraction_agent/) and reference them using the output_schema parameter. Learn more about prompt structure and schemas →

Structured Output Schemas

When using structured output:

• The response will have content_type of application/json
• The response content will be valid JSON matching your schema
• Parse the response with JSON.parse(response.message.content)

Generating Schemas from Models

ActiveAgent provides a SchemaGenerator module that can automatically create JSON schemas from your ActiveRecord and ActiveModel classes. This makes it easy to ensure extracted data matches your application's data models.

Basic Usage

schema_generator_test.rb

class TestUser
  include ActiveModel::Model
  include ActiveModel::Attributes
  include ActiveModel::Validations
  include ActiveAgent::SchemaGenerator

  attribute :name, :string
  attribute :email, :string
  attribute :age, :integer
  attribute :active, :boolean

  validates :name, presence: true, length: { minimum: 2, maximum: 100 }
  validates :email, presence: true, format: { with: URI::MailTo::EMAIL_REGEXP }
  validates :age, numericality: { greater_than_or_equal_to: 18 }
end

schema_generator_test.rb

schema = TestUser.to_json_schema

The to_json_schema method generates a JSON schema from your model's attributes and validations.

Schema with Validations

Model validations are automatically included in the generated schema:

schema = TestUser.to_json_schema

Strict Schema for Structured Output

For use with AI providers that support structured output, generate a strict schema:

schema_generator_test.rb

class TestBlogPost
  include ActiveModel::Model
  include ActiveModel::Attributes
  include ActiveModel::Validations
  include ActiveAgent::SchemaGenerator

  attribute :title, :string
  attribute :content, :string
  attribute :published_at, :datetime
  attribute :tags, :string
  attribute :status, :string

  validates :title, presence: true, length: { maximum: 200 }
  validates :content, presence: true
  validates :status, inclusion: { in: [ "draft", "published", "archived" ] }
end

schema_generator_test.rb

schema = TestBlogPost.to_json_schema(strict: true, name: "blog_post_schema")

Using Generated Schemas in Agents

Agents can use the schema generator to create structured output schemas dynamically:

# Generate schema from model - returns a Ruby hash
user_schema = TestUser.to_json_schema(strict: true, name: "user_extraction")

# In actual usage, the agent would use the hash directly:
# prompt(output_schema: user_schema)

This allows you to maintain a single source of truth for your data models and automatically generate schemas for AI extraction.

Provider Support

Structured output requires a generation provider that supports JSON schemas. Currently supported providers include:

• OpenAI - GPT-4o, GPT-4o-mini, GPT-3.5-turbo variants
• OpenRouter - When using compatible models like OpenAI models through OpenRouter

See the OpenRouter Provider documentation for details on using structured output with multiple model providers.

Parse Chart Image with Structured Output

Extract chart data with a predefined schema chart_schema:

data_extraction_agent_test.rb

prompt = DataExtractionAgent.with(
  output_schema: :chart_schema,
  image_path: sales_chart_path
).parse_content

chart_schema.json.erb

{
  "format": {
    "type": "json_schema",
    "name": "chart_schema",
    "schema": {
      "type": "object",
      "properties": {
        "title": {
          "type": "string",
          "description": "The title of the chart."
        },
        "data_points": {
          "type": "array",
          "items": {
            "$ref": "#/$defs/data_point"
          }
        }
      },
      "required": ["title", "data_points"],
      "additionalProperties": false,
      "$defs": {
        "data_point": {
          "type": "object",
          "properties": {
            "label": {
              "type": "string",
              "description": "The label for the data point."
            },
            "value": {
              "type": "number",
              "description": "The value of the data point."
            }
          },
          "required": ["label", "value"],
          "additionalProperties": false
        }
      }
    }
  }
}

Response

response = prompt.generate_now

Generation Response Example

activeagent/test/agents/data_extraction_agent_test.rb:145

# Response object
#<ActiveAgent::GenerationProvider::Response:0x31ec
  @message=#<ActiveAgent::ActionPrompt::Message:0x3200
    @action_id=nil,
    @action_name=nil,
    @action_requested=false,
    @charset="UTF-8",
    @content={"title"=>"Quarterly Sales Report", "data_points"=>[{"label"=>"Q1", "value"=>25000}, {"label"=>"Q2", "value"=>50000}, {"label"=>"Q3", "value"=>75000}, {"label"=>"Q4", "value"=>100000}]},
    @role=:assistant>
  @prompt=#<ActiveAgent::ActionPrompt::Prompt:0x3214 ...>
  @content_type="application/json"
  @raw_response={...}>

# Message content
response.message.content # => {"title"=>"Quarterly Sales Report", "data_points"=>[{"label"=>"Q1", "value"=>25000}, {"label"=>"Q2", "value"=>50000}, {"label"=>"Q3", "value"=>75000}, {"label"=>"Q4", "value"=>100000}]}

Parse Resume with output resume schema

Extract information from PDF resumes:

data_extraction_agent_test.rb

prompt = DataExtractionAgent.with(
  output_schema: :resume_schema,
  file_path: sample_resume_path
).parse_content

resume_schema.json.erb

{
  "format": {
    "type": "json_schema",
    "name": "resume_schema",
    "schema": {
      "type": "object",
      "properties": {
        "name": {
          "type": "string",
          "description": "The full name of the individual."
        },
        "email": {
          "type": "string",
          "format": "email",
          "description": "The email address of the individual."
        },
        "phone": {
          "type": "string",
          "description": "The phone number of the individual."
        },
        "education": {
          "type": "array",
          "items": {
            "$ref": "#/$defs/education"
          }
        },
        "experience": {
          "type": "array",
          "items": {
            "$ref": "#/$defs/experience"
          }
        }
      },
      "required": ["name", "email", "phone", "education", "experience"],
      "additionalProperties": false,
      "$defs": {
        "education": {
          "type": "object",
          "properties": {
            "degree": {
              "type": "string",
              "description": "The degree obtained."
            },
            "institution": {
              "type": "string",
              "description": "The institution where the degree was obtained."
            },
            "year": {
              "type": "integer",
              "description": "The year of graduation."
            }
          },
          "required": ["degree", "institution", "year"],
          "additionalProperties": false
        },
        "experience": {
          "type": "object",
          "properties": {
            "job_title": {
              "type": "string",
              "description": "The job title held."
            },
            "company": {
              "type": "string",
              "description": "The company where the individual worked."
            },
            "duration": {
              "type": "string",
              "description": "The duration of employment."
            }
          },
          "required": ["job_title", "company", "duration"],
          "additionalProperties": false
        }
      }
    },
    "strict": true
  }
}

Parse Resume with Structured Output

Extract resume data with a predefined resume_schema:

response = prompt.generate_now

Generation Response Example

activeagent/test/agents/data_extraction_agent_test.rb:79

# Response object
#<ActiveAgent::GenerationProvider::Response:0x314c
  @message=#<ActiveAgent::ActionPrompt::Message:0x3160
    @action_id=nil,
    @action_name=nil,
    @action_requested=false,
    @charset="UTF-8",
    @content={"name"=>"John Doe", "email"=>"john.doe@example.com", "phone"=>"(555) 123-4567", "education"=>[{"degree"=>"BS Computer Science", "institution"=>"Stanford University", "year"=>2020}], "experience"=>[{"job_title"=>"Senior Software Engineer", "company"=>"TechCorp", "duration"=>"2020-2024"}]},
    @role=:assistant>
  @prompt=#<ActiveAgent::ActionPrompt::Prompt:0x3174 ...>
  @content_type="application/json"
  @raw_response={...}>

# Message content
response.message.content # => {"name"=>"John Doe", "email"=>"john.doe@example.com", "phone"=>"(555) 123-4567", "education"=>[{"degree"=>"BS Computer Science", "institution"=>"Stanford University", "year"=>2020}], "experience"=>[{"job_title"=>"Senior Software Engineer", "company"=>"TechCorp", "duration"=>"2020-2024"}]}

Advanced Examples

Receipt Data Extraction with OpenRouter

For extracting data from receipts and invoices, you can use OpenRouter's multimodal capabilities combined with structured output. OpenRouter provides access to models that support both vision and structured output, making it ideal for document processing tasks.

See the OpenRouter Receipt Extraction example for a complete implementation that extracts:

• Merchant information (name, address)
• Line items with prices
• Tax and total amounts
• Currency details

Using Different Providers

The Data Extraction Agent can work with any generation provider that supports the required capabilities:

• For text extraction: Any provider (OpenAI, Anthropic, Ollama, etc.)
• For image analysis: Providers with vision models (OpenAI GPT-4o, Anthropic Claude 3, etc.)
• For structured output: OpenAI models or OpenRouter with compatible models
• For PDF processing: OpenRouter with PDF plugins or models with native PDF support

Provider Selection

Choose your provider based on your specific needs:

• OpenAI: Best for structured output with GPT-4o/GPT-4o-mini
• OpenRouter: Access to 200+ models with fallback support
• Anthropic: Strong reasoning capabilities with Claude models
• Ollama: Local model deployment for privacy-sensitive data

Learn more about configuring providers in the Generation Provider Overview.
